Bosch NBC-455-11P SD Fixed IP Hemisphere Camera，Color 1/3"Progressive scan,H.264，PAL，50Hz，PoE，microSD Slot
Product Numbers:NBC-455-11P
Price:0
Product introduction:Bosch NBC-455-11P SD Fixed IP Hemisphere Camera，Color 1/3"Progressive scan,H.264，PAL，50Hz，PoE，microSD Slot
Bosch NBC-455-11P SD Fixed IP Hemisphere Camera，Color 1/3"Progressive scan,H.264，PAL，50Hz，PoE，microSD Slot
A third of an inch color CCD with progressive scan technique
Four stream
Flexible video options
The front-end intelligence technology
Accord with standard of ONVIF
Automatic camera detection, including the lens wizard
Type of rated voltage
NBC - 455-1 24 VAC xp plus or minus 10%
12 VDC plus or minus 10%
Ethernet power supply
NBC - 455-2-24 VAC xp plus or minus 10%
12 VDC plus or minus 10%
Ethernet power supply
Current consumption of 450 mA | 450 mA IVA (12 VDC) 450 mA | 550 mA IVA (24 VAC) 200 mA | 250 mA IVA 48 VDC (PoE)
5.4 W power consumption 5.4 W | IVA (12 VDC) | 8.2 6.7 W W IVA (24 VAC) 9.6 W (PoE 48 VDC)
sensors
Type a third of an inch CCD
Effective image (PAL) 752 x 582 pixels
Effective image 768 x 494 pixels (NTSC)
video
H. 264 video compression (ISO/IEC 14496-10);M - JPEG, JPEG
Data transfer rate of 9.6 Kbps to 6 Mbps
Vertical resolution level x (PAL/NTSC ips)
4 cif 704 x 576/480 25/30 (ips)
CIF 352 x 288/240 25/30 (ips)
Overall IP delay at least 120 milliseconds, up to 240 milliseconds
GOP structure I, IP, IBBP
Frame rate 1 to 50/60 (PAL/NTSC) h. 2641 to 25/30 (PAL/NTSC) M - JPEG
Video output
Signal analog composite (NTSC or PAL), service
The connector BNC, 75 ohms
Horizontal resolution 540 TV lines
Video signal to noise ratio of 50 dB
Reflectivity of 89% sensitivity (3200 K, scene, pro series)
