SONY SSC-G113 simulation gun type camera

SSC - G113 simulation gun type camera
SONY simulation gun camera SSC - G113, adopted a third of an inch SONY EXview HAD CCD II, with the latest DSP platform "Effio E", in 650 lines of high resolution, high quality images at the same time, provides exceptional sensitivity performance, even in low light environment also can ensure a high quality image. And the camera has transformation function, the ATR - day and night Lite automatic dark space compensation function and iBLC intelligent backlight compensation function, image restore true, fine and good effect. Excellent performance, ultra low power design of SSC - G113 gun camera is the ideal choice for all kinds of monitoring application.
High quality, high resolution images
By using the advanced DSP technology, so as to realize the definition of the 540 line, provides a clear, detailed images beyond imagination.
High sensitivity
Using a third of an inch EXview CCD II
Electronic conversion function day and night
Transformation function, day and night, can switch automatically according to the light changes color or black and white pattern.
Backlight compensation
IBLC smart backlight compensation function, can improve dark space brightness.
Automatic gain control (AGC)
Equipped with advanced automatic gain function, for monitoring under low illumination.
Digital noise reduction function
2 d / 3 d digital noise reduction function, can effectively eliminate the noise, guarantee the image clearly.
Low power consumption
Ultra low power design, maximum power 1.6 W.
In both Chinese and English menu operation
Can achieve convenient, quick setting and operation.
The camera
Imaging device
A third of an inch EXview HAD CCD II
Effective pixels (H (V)
570000 pixels (976 x 582)
Signal system
PAL
Level of clarity
650 TVL
Signal to noise ratio
St13 55 db (AGC Off)
Minimum illumination
Color 0.15 lx, black and white 0.1 lx (pro series, 50 ire () 0.08 lx color, black and white 0.03 lx (pro series, 30 ire ()
Analog video output
1.0 the Vp - p
Signal synchronization
Power supply/in sync
Gain control
Automatic (on/off)
The white balance
ATW (2000 k to 10000 k), ATW - PRO (2500 k to 6000 k)
The lens type
CS interface
features
Day and night functionality
Support (electronic)
Digital noise reduction
Support (NR) 2 d
Backlight compensation
Support (iBLC)
Automatic dark space compensation
Support (ATR - Lite)
The general specification
The weight of the
250 g
size
117.6 * 63.2 * 63.2 mm
The power supply
AC24V, DC12V
power
1.4 W.
Working temperature
- 10 ℃ - + 50 ℃
Storage temperature
-- 40 ℃ - + 60 ℃
Working humidity
20% - 80%
Store humidity
20% - 95%
accessories
Instructions, lens cap
